YIG Microwave ferrite Narrow Line Width Yttrium Iron Garnets Ca V Doped

Product Description

C&Y TECHNOLOGY CO., LIMITED
E-mail: magnet886@gmail.com
WhatsApp:+8615867408815
Skype:Mark-magnet

https://www.microwaveferrite.com

Characteristics
In recent years due to success in the field of microwave electronics a lot of devices of dfferent applications were produced. The prospects for future development of
microwave systems with predetermined characteristics are mainly assigned by ferrite choise. However the choise of a material for a concrete application in microwave
technique is a complicated task, as there are different requirements to different parts of microwave band. Among main characteristics of ferrites suitable for high
frequencies are:
1.At the expense of high specic etrial rsistvity (p >106 Om:sm) ferrites are characterised by low deletric lsses at high frequencies tg-10-2+104).
2.Dielectric permittivity(about 10-15)
3.Thermal stability in a wide temperature range
4.The high activity is being determined by the value of minimal bias which is essential for required nominal parameters providing.
5.Saturation magnetization, M s; 4Ms (400-5000 G)
6.The width of resonance curve 20H is one of the main parameters characterising properties of frrites applied in high-frequency band. The yttrium-iron monocrystals exhibit the minimal value 2H =0.3-0.5 Oe. The width of resonanse curve of plytalline frrites varies from 3...40 to 800-1000 Oe.

Configurations
Microwave ferrites and ceramics are being produced on the base of pressed powder sintered at high temperatures. After thermal sintering the items can be smoothed and/or polished. Company produces items with different forms. Dimensional allowance at mechanical treatment is 0,02 mm. In spite of standard variants of performance it is possible to produce ferrites in accoradance with sizes and customers drawings.

Microwave ferrite shapes:

Disk	Diameter: 1-55 mm
Plate	Max size: 50.8 x 50.8mm Thickness: 0.5-3 mm
Triangle	Max diameter: 12mm
Rod	Max length: 90 mm
Composition	Ferrites and dielectric materials



Microwave Ferrite Materials:If you require any further information, feel free to contact me:
C&Y TECHNOLOGY CO., LIMITED

https://www.microwaveferrite.com

Engineered for Precision Microwave Applications

YIG microwave ferrite components doped with calcium and vanadium are specifically designed for exceptional performance in high-frequency environments. Their narrow line width, low magnetic anisotropy, and fine polished surfaces contribute to minimal signal loss and superior device reliability. This makes them indispensable in industries requiring precision such as telecommunications, radar, and scientific instrumentation.


Custom Solutions for Diverse Requirements

Whether your project demands tailored diameter, unique shapes, or specific doping concentrations, we offer flexible options. From standard discs and spheres to complex geometries, our manufacturing process accommodates both small and large-scale needs. Each product is delivered in standard ESD-safe packaging or customized per customer specifications, ensuring safe handling and transportation.
