NG Narrow Line Width Garnet Microwave ferrite
Product Details:
- Power High Power Compatible
- Application Microwave Devices, Isolators, Circulators, Filters, Phase Shifters
- Composite Garnet Microwave Ferrite
- Material Single Crystal Yttrium Iron Garnet (YIG) or Substituted Garnet Material
- Surface Finish Polished, Optical Grade
- Magnet Grade Custom as per client specification
- Frequency 220 GHz
- Click to View more
X
NG Narrow Line Width Garnet Microwave ferrite Price And Quantity
- 1000 Piece
NG Narrow Line Width Garnet Microwave ferrite Product Specifications
- 220 GHz
- Microwave Communication, Radar, Satellite Communication, Electronic Countermeasures
- Custom as per client specification
- Polished, Optical Grade
- Dark Brown/Black
- Single Crystal Yttrium Iron Garnet (YIG) or Substituted Garnet Material
- Narrow Line Width Garnet Ferrite
- Garnet Microwave Ferrite
- Disc, Rectangle, Custom Shapes
- Microwave Devices, Isolators, Circulators, Filters, Phase Shifters
- Ferrite
- Customized; Diameter 250 mm, Thickness 0.210 mm
- Microwave Ferrite
- High Power Compatible
- Custom as per requirement
NG Narrow Line Width Garnet Microwave ferrite Trade Information
- Paypal, Western Union, Telegraphic Transfer (T/T)
- 100000 Piece Per Month
- 25 Days
- All India
Product Description
Ningbo Chiyue Magnet Factory is a domestic recognized leader in the field of Microwave ferrite/gyromagnetic ferrite in China .Based on many years' scientific and practical experience,we produce and sell in the area of magnetism and its applications.
Any question,Please contact us:
E-mail: magnet886@gmail.com.
WhatsApp:+8615867408815;
Skype:Mark-magnet;
Narrow LineWidth Garnet Microwave Ferrite Material -YIG Series :
YGA Moderate continuous power material series:
Spinal nickel gyramagnetic microwave ferrite material series:
Spinal nickel gyramagnetic microwave ferrite power material series:
Spinal lithium microwave ferrite material series:
Spinal lithium microwave ferrite power material series:
Microwave Ferrites, Microwave Ferrite and Ceramic, Garnet & Ferrite (Microwave), Narrow Linewidth Ferrite Material, Microwave Ferrite Based Components, Nickel Spinels Microwave Ferrite, Lithium Spinels Microwave Ferrite
Introduction
Microwave ferrite magnets can generate constant magnetic field to control electric current so that microwave signal is amplified and information can be smoothly transmitted. Microwave magnets are widely used in magnetrons, cathode-ray tubes, isolators, circulator, etc. These electronic components are commonly applied in radars, satellite communications, remote control systems, electronic tracking, electronic countermeasures, etc.
Precision Engineering for Advanced Microwave Devices
Designed for critical applications, NG Narrow Line Width Garnet Microwave Ferrite achieves superior performance in frequency ranges from 2 to 20 GHz. Its high-purity composition and minimal magnetic inhomogeneity support exacting standards required for microwave communication, radar, and satellite technology. The customizable size, shape, and chemical structure enable integration into a variety of specialized microwave components, ensuring optimal efficiency and signal fidelity.
Reliable Performance with Robust Temperature Stability
This garnet microwave ferrite maintains magnetic and electrical stability across extended temperature ranges, performing consistently up to 150C. Its low aging rates (<0.01% per year) and controlled loss tangent ensure long-term reliability, making it suitable for both civilian and military applications needing uninterrupted performance and minimal maintenance.
FAQ's of NG Narrow Line Width Garnet Microwave ferrite:
Q: How is the NG Narrow Line Width Garnet Microwave Ferrite manufactured to achieve high purity and magnetic homogeneity?
A: This ferrite is produced using the Czochralski crystal growth method, which allows precise control over crystal formation. Stringent quality assurance ensures magnetic homogeneity (1%) and high purity (>99.9%), meeting rigorous specifications for advanced microwave applications.Q: What makes this microwave ferrite ideal for high-frequency applications?
A: Its narrow line width (<1.0 Oe at 9.5 GHz), low loss tangent (<210^-5), and stable dielectric constant (r: 14.50.5) provide excellent performance in the 2-20 GHz range, minimizing insertion loss and supporting efficient signal transmission in devices such as isolators, circulators, and filters.Q: When is custom sizing and chemical composition available for this microwave ferrite?
A: Custom dimensions (diameter, thickness, and shape) and chemical formulas are offered regardless of order size, from a minimum of one piece. This flexibility ensures compatibility with diverse design needs and device requirements across different industries.Q: Where can NG Narrow Line Width Garnet Microwave Ferrite be used?
A: It is extensively applied in microwave communication systems, radar arrays, satellite communication, and electronic countermeasures across defense, aerospace, and telecommunication sectors due to its adaptable material properties and reliable performance.Q: What is the process for ordering and receiving this ferrite material?
A: Clients may request customized specifications, and each order is securely packaged in anti-static containers for safe transit. The product complies with RoHS and REACH standards, ensuring global regulatory acceptance, and can be shipped internationally from China according to customer needs.Q: What are the benefits of using this microwave ferrite in demanding environments?
A: End-users gain ultra-low signal loss, exceptional temperature resilience up to 150C, stable magnetic properties, and long-term reliability (<0.01% aging per year), making it a preferred choice for mission-critical and high-power microwave systems.Tell us about your requirement
